Vue图形验证码
组件
可以自行封装一下,放在components目录下。
<template><span class="s-canvas" @click="changeCode"><canvas id="s-canvas" :width="contentWidth" :height="contentHeight"></canvas></span>
</template><script>
export default {name: "Code",data() {return {identifyCode: ""}},props: {identifyCodes: {//验证码从该字段中抽取生成type: String,default: "1234567890ABCDEFGHIJKLMNOPQRSTUVWXYZ"},fontSizeMin: {// 字体最小值type: Number,default: 25},fontSizeMax: {// 字体最大值type: Number,default: 35},backgroundColorMin: {// 验证码图片背景色最小值type: Number,default: 200},backgroundColorMax: {// 验证码图片背景色最大值type: Number,default: 220},dotColorMin: {// 背景干扰点最小值type: Number,default: 60},dotColorMax: {// 背景干扰点最大值type: Number,default: 120},contentWidth: {//容器宽度type: Number,default: 100},contentHeight: {//容器高度type: Number,default: 44}},watch: {identifyCode() {this.drawPic();}},mounted() {this.drawPic();this.makeCode(this.identifyCodes, 4);},methods: {// 生成一个随机数randomNum(min, max) {return Math.floor(Math.random() * (max - min) + min);},// 生成一个随机的颜色randomColor(min, max) {let r = this.randomNum(min, max);let g = this.randomNum(min, max);let b = this.randomNum(min, max);return "rgb(" + r + "," + g + "," + b + ")";},drawPic() {let canvas = document.getElementById("s-canvas");let ctx = canvas.getContext("2d");ctx.textBaseline = "bottom";// 绘制背景ctx.fillStyle = this.randomColor(this.backgroundColorMin,this.backgroundColorMax);ctx.fillRect(0, 0, this.contentWidth, this.contentHeight);// 绘制文字for (let i = 0; i < this.identifyCode.length; i++) {this.drawText(ctx, this.identifyCode[i], i);}this.drawLine(ctx);this.drawDot(ctx);},drawText(ctx, txt, i) {ctx.fillStyle = this.randomColor(50, 160); //随机生成字体颜色ctx.font =this.randomNum(this.fontSizeMin, this.fontSizeMax) + "px SimHei"; //随机生成字体大小let x = (i + 1) * (this.contentWidth / (this.identifyCode.length + 1));let y = this.randomNum(this.fontSizeMax, this.contentHeight - 5);var deg = this.randomNum(-30, 30);// 修改坐标原点和旋转角度ctx.translate(x, y);ctx.rotate((deg * Math.PI) / 180);ctx.fillText(txt, 0, 0);// 恢复坐标原点和旋转角度ctx.rotate((-deg * Math.PI) / 180);ctx.translate(-x, -y);},drawLine(ctx) {// 绘制干扰线for (let i = 0; i < 4; i++) {ctx.strokeStyle = this.randomColor(100, 200);ctx.beginPath();ctx.moveTo(this.randomNum(0, this.contentWidth),this.randomNum(0, this.contentHeight));ctx.lineTo(this.randomNum(0, this.contentWidth),this.randomNum(0, this.contentHeight));ctx.stroke();}},drawDot(ctx) {// 绘制干扰点for (let i = 0; i < 30; i++) {ctx.fillStyle = this.randomColor(0, 255);ctx.beginPath();ctx.arc(this.randomNum(0, this.contentWidth),this.randomNum(0, this.contentHeight),1,0,2 * Math.PI);ctx.fill();}},/*切换验证码start*/changeCode() {this.identifyCode = "";this.makeCode(this.identifyCodes, 4);},makeCode(e, n) {for (let i = 0; i < n; i++) {this.identifyCode += e[this.randomNum(0, e.length)];}this.$emit("update:changeCode", this.identifyCode);},randomNum(min, max) {return Math.floor(Math.random() * (max - min) + min);}/*切换验证码end*/}
};
</script>
view页面使用
ps:在跟用户输入上的验证码,进行对比的时候可以统一把验证码的英文字母统一转换一下,要么全是大写,要么全是小写。
<template><div><VerificationCode :changeCode.sync='identifyCode'></VerificationCode></div>
</template><script>
import VerificationCode from '@/components/common/VerificationCode ';
export default {components: {VerificationCode },data() {return {identifyCode:'', //当前生成的验证码}}
}
</script>
